| Type |
Frame |
| Model |
ZALMAN Z10 |
| Case Size |
ATX Mid-Tower |
| Motherboard Orientation |
Vertical |
| Dimensions (L × W × H) |
481 × 220 × 488 mm |
| Weight |
8 kg |
| Main Color |
Black |
| Material |
Steel, Tempered Glass, Plastic |
| Metal Thickness |
0.4 mm |
| Side Window |
Yes, on the left |
| Window Material |
Tempered Glass |
| Front Panel Material |
Plastic, Tempered Glass |
| Backlight Control |
Button on the case |
| Compatible Motherboard Form Factors |
E-ATX, ATX, Micro-ATX, Mini-ITX |
| Compatible PSU Form Factor |
ATX |
| Max PSU Length |
200 mm |
| Expansion Slots (Horizontal) |
7 |
| Expansion Slots (Vertical) |
3 |
| Max GPU Length |
395 mm |
| Max CPU Cooler Height |
173 mm |
| 2.5" Drive Bays |
2 |
| 3.5" Drive Bays |
2 |
| Included Fans |
Front: 3 × 140mm (Black), Rear: 1 × 120mm (Black) |
| Front Fan Support |
3 × 120mm / 3 × 140mm |
| Rear Fan Support |
1 × 120mm |
| Top Fan Support |
3 × 120mm / 2 × 140mm |
| Bottom Fan Support |
2 × 120mm |
| Side Fan Support |
2 × 120mm |
| Liquid Cooling Support |
Yes |
| Top Radiator Support |
120mm / 140mm / 240mm / 280mm / 360mm |
| I/O Panel Location |
Bottom-side |
| Front Panel Connectors |
1× Headphones, 1× Mic, 2× USB 3.0, 1× USB Type-C, Reset Button, LED Button, Power Button, (Mini-HDMI, USB Type-C) |
| Side Panel Fixing |
Screws on the side |
| CPU Cooler Cutout |
Yes |
| Cable Management (Behind MB Tray) |
Yes |
| Dust Filters |
Yes |
| Built-in PSU |
No |
| Package Contents |
Documentation, fastener set |
